模型名稱
GT-BE98網路標準
Wi-Fi 6 (802.11ax)WiFi 7 (802.11be)
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IPv4
IPv6
產品區段
BE25000 ultimate BE performance : 1376+5764+5764+11529 Mbps數據速率
2.4GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps5G-1Hz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbp
5G-2Hz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbp
6GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbp
天線
External antenna x 8傳送/接收
2.4 GHz 4 x 45 GHz-1 4 x 4
5 GHz-2 4 x 4
6GHz 4x4
處理器
2.6GHz quad-core processor記憶體
256 MB Flash and 2 GB RAMWi-Fi技術
OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 4096-QAM high data rate 20/40/80/160/320 MHz bandwidth運作頻率
2.4 GHz / 5 GHz / 6 GHzOperating Mode
Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge連接埠
1 x 10Gbps for WAN/LAN 1 x 2.5Gbps for WAN/LAN 1 x 10Gbps for LAN 3 x 2.5Gbps for LAN 1 x RJ45 10/100/1000Mbps for LAN 1 x USB 3.2 Gen1 1 x USB 2.0按鍵
WPS Button, Reset Button, Power Switch, LED control ButtonLED指示燈
WAN(Internet) x1 10G LAN x1 1G/2.5G LAN x1 6GHz x1 5GHz-1 x 1 5GHz-2 x 1 2.4GHz x1 Power x1電源
AC Input : 110V~240V(50~60Hz) DC Output : 19.5 V with max. 3.33 A current套包內容
GT-BE98 quad-band gaming router RJ-45 cable Power adapter Quick Start Guide Warranty card產品重量 (克)
2000 gProduct Dimensions
350.41 x 350.41 x 220.6 mmAiMesh
是遊戲
是家長控制
是• Maximum Parental Control profile : 64
• Maximum Parental Control content filter rule : 64
Guest Network
是• Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 5
Guest Network Connection time limit
Guest Network Encryption : Open system, WPA/WPA2/WPA3 Personal
Security
WiFi Encryption : WPA/WPA2/WPA3 Personal WPA/WPA2/WPA3 Enterprise Open System & OWE是
Let's Encrypt
DNS-over-TLS
SSH
Security Scan
Firewall
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
AiProtection
AiProtection Pro是
VPN
Instant GuardVPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
訊務控制
是-- Maximum Bandwidth Limiter Rule : 32
• Traffic Analysis Period : Daily, Weekly, Monthly
WAN
Internet Connection Type : Automatic IP, Static IP, PPPoE, PPTP, L2TPDual WAN
3G / 4G LTE Dongle
4G / 5G Auto Mobile Tethering
Port Forwarding
• Maximum Port Forwarding Rule : 64
Port Triggering
• Maximum Port Triggering Rule : 32
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
LAN
DHCP ServerIPTV
LAN Link Aggregation
Manually Assign IP Address
• Maximum Manually Assign IP Address Rule : 128
Wake on LAN (WOL)
無線
是• Maximum MAC Filters : 64
Airtime Fairness
RADIUS Client
Universal Beamforming
Explicit Beamforming
USB應用
4G / 5G Auto Mobile TetheringFile System : HFS+, NTFS, vFAT, ext2, ext3, ext4
Safely Remove Disk
AiCloud
Download Master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder Privileges
User Interface
Operating system : ASUSWRT管理
Configuration Backup and Restore
Diagnosis Tools
Feedback System
System Log
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update
- WiFi 7 features require WiFi routers and client devices with WiFi 7-supported operating systems to support the corresponding features.
- 6GHz band is limited to indoor range. Clients must support 6GHz band.
- The 320 MHz in the 6 GHz band may be unavailable in some regions / countries due to regulatory restrictions.
- If no 6 GHz SSID is displayed, please check whether your OS and client device are fully licensed to support the 6 GHz band.
- The Multi-link Operation feature require a WiFi 7 capable device. Firmware support for Multi-link Operation (MLO) is in development and will be released in late 2023 or early 2024.
