模型名稱

GT-BE98

網路標準

Wi-Fi 6 (802.11ax)
WiFi 7 (802.11be)
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IPv4
IPv6

產品區段

BE25000 ultimate BE performance : 1376+5764+5764+11529 Mbps

數據速率

2.4GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps
5G-1Hz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbp
5G-2Hz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbp
6GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbp

天線

External antenna x 8

傳送/接收

2.4 GHz 4 x 4
5 GHz-1 4 x 4
5 GHz-2 4 x 4
6GHz 4x4

處理器

2.6GHz quad-core processor

記憶體

256 MB Flash and 2 GB RAM

Wi-Fi技術

OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 4096-QAM high data rate 20/40/80/160/320 MHz bandwidth

運作頻率

2.4 GHz / 5 GHz / 6 GHz

Operating Mode

Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge

連接埠

1 x 10Gbps for WAN/LAN 1 x 2.5Gbps for WAN/LAN 1 x 10Gbps for LAN 3 x 2.5Gbps for LAN 1 x RJ45 10/100/1000Mbps for LAN 1 x USB 3.2 Gen1 1 x USB 2.0

按鍵

WPS Button, Reset Button, Power Switch, LED control Button

LED指示燈

WAN(Internet) x1 10G LAN x1 1G/2.5G LAN x1 6GHz x1 5GHz-1 x 1 5GHz-2 x 1 2.4GHz x1 Power x1

電源

AC Input : 110V~240V(50~60Hz) DC Output : 19.5 V with max. 3.33 A current

套包內容

GT-BE98 quad-band gaming router RJ-45 cable Power adapter Quick Start Guide Warranty card

產品重量 (克)

2000 g

Product Dimensions

350.41 x 350.41 x 220.6 mm

AiMesh

是

遊戲

是

家長控制

是
• Maximum Parental Control profile : 64
• Maximum Parental Control content filter rule : 64

Guest Network

是
• Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 5
Guest Network Connection time limit
Guest Network Encryption : Open system, WPA/WPA2/WPA3 Personal

Security

WiFi Encryption : WPA/WPA2/WPA3 Personal WPA/WPA2/WPA3 Enterprise Open System & OWE
是
Let's Encrypt
DNS-over-TLS
SSH
Security Scan
Firewall
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64

AiProtection

AiProtection Pro
是

VPN

Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion

訊務控制

是
-- Maximum Bandwidth Limiter Rule : 32
• Traffic Analysis Period : Daily, Weekly, Monthly

WAN

Internet Connection Type : Automatic IP, Static IP, PPPoE, PPTP, L2TP
Dual WAN
3G / 4G LTE Dongle
4G / 5G Auto Mobile Tethering
Port Forwarding
• Maximum Port Forwarding Rule : 64
Port Triggering
• Maximum Port Triggering Rule : 32
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay

LAN

DHCP Server
IPTV
LAN Link Aggregation
Manually Assign IP Address
• Maximum Manually Assign IP Address Rule : 128
Wake on LAN (WOL)

無線

是
• Maximum MAC Filters : 64
Airtime Fairness
RADIUS Client
Universal Beamforming
Explicit Beamforming

USB應用

4G / 5G Auto Mobile Tethering
File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
Safely Remove Disk
AiCloud
Download Master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder Privileges

User Interface

Operating system : ASUSWRT

管理

Configuration Backup and Restore
Diagnosis Tools
Feedback System
System Log
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update



• WiFi 7 features require WiFi routers and client devices with WiFi 7-supported operating systems to support the corresponding features.
• 6GHz band is limited to indoor range. Clients must support 6GHz band.
• The 320 MHz in the 6 GHz band may be unavailable in some regions / countries due to regulatory restrictions.
• If no 6 GHz SSID is displayed, please check whether your OS and client device are fully licensed to support the 6 GHz band.
• The Multi-link Operation feature require a WiFi 7 capable device. Firmware support for Multi-link Operation (MLO) is in development and will be released in late 2023 or early 2024.
• 經由美國聯邦通信委員會及加拿大工業部認證的產品會於美國及加拿大販售。請造訪 ASUS USA 及 ASUS Canada 以獲得當地產品的資訊。
• 產品規格及資訊會隨時更新，恕不另行通知，請與供應商聯繫以獲得確切資訊。各地區所販售的產品可能不同。
• 產品規格及特色會因機型而有所差異，所有圖片也皆為說明用途，完整細節詳見產品規格頁面。
• PCB 顏色及軟體版本會隨時更新，恕不另行通知。
• 商標聲明: 本網站所談論到的產品名稱僅做識別之用，而這些名稱可能是屬於其他公司的註冊商標或是版權。
• 本網站所提到的產品規格、應用程式、圖片及資訊僅提供參考，內容會隨時更新，恕不另行通知。
• USB 3.0、USB3.1、USB3.2以及Type-C的實際傳輸速度將依據您的使用情境而變化，包括電腦的設備、檔案的規格以及系統配置和操作相關的其他因素而影響處理速度。
